|                  Linux Network Stack vs Kernel Bypass Architectures                     |
+-----------------------------------------------------------------------------------------+

TRADITIONAL LINUX SOCKET (posix epoll + recv):
[NIC] ---> [Kernel Driver] ---> [Allocates sk_buff] ---> [TCP/IP Stack] ---> [Copy to User App]
* Bottleneck: Multiple memory copies + interrupt context switches. Max: ~1.5 Mpps per core.

XDP (eXpress Data Path - In-Driver eBPF):
[NIC] ---> [NIC Driver: XDP BPF Program] ---> [XDP_DROP (DDoS mitigation) / XDP_TX (Redirect)]
* Efficiency: Drops or routes packets in < 15 nanoseconds before allocating kernel memory!

AF_XDP (Zero-Copy UMEM Ring Buffer - 2026 Gold Standard):
[NIC DMA Hardware] ===(Direct Memory Access: Zero Copies!)===> [UMEM Shared Memory Ring]
                                                                        │
                                                                        ▼
                                                             [User Space Application]
* Best of Both Worlds: ~25-40 Mpps per core without breaking standard Linux network drivers!

DPDK (Full Userspace Kernel Bypass):
[NIC] ===(Direct Poll Mode Driver (PMD) - Kernel Completely Bypassed!)===> [User Space App]
* Max Performance: ~50-80 Mpps per core, but requires dedicated 100% CPU polling & custom drivers.

+-----------------------------------------------------------------------------------------+
|                  Architectural Matrix: DPDK vs AF_XDP vs io_uring (2026)                |
+-----------------------------------------------------------------------------------------+

+-----------------------------------------------------------------------------------------+
|                  AF_XDP UMEM Shared Memory Ring Buffers                                 |
+-----------------------------------------------------------------------------------------+

[USER SPACE APPLICATION] <====================================> [LINUX KERNEL DRIVER]
                          CONTIGUOUS MEMORY POOL (UMEM)

  1. FILL RING (User -> Kernel):
     - Application populates ring with available memory buffer addresses (frames).

  2. RX RING (Kernel -> User):
     - NIC DMAs incoming packet directly into frame -> Kernel notifies user via RX ring!

  3. TX RING (User -> Kernel):
     - Application places outbound packet frames onto TX ring for transmission.

  4. COMPLETION RING (Kernel -> User):
     - Kernel notifies application that frame transmission is finished and memory is free!

// src/af_xdp_receiver.c
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <unistd.h>
#include <sys/mman.h>
#include <bpf/xsk.h>
#include <linux/if_link.h>

#define NUM_FRAMES 4096
#define FRAME_SIZE XSK_UMEM__DEFAULT_FRAME_SIZE // 4096 Bytes
#define BATCH_SIZE 64

struct xsk_umem_info {
    struct xsk_ring_prod fq; // Fill Queue
    struct xsk_ring_cons cq; // Completion Queue
    struct xsk_umem *umem;
    void *buffer;
};

struct xsk_socket_info {
    struct xsk_ring_cons rx; // RX Receive Queue
    struct xsk_ring_prod tx; // TX Transmit Queue
    struct xsk_socket *xsk;
    struct xsk_umem_info *umem;
};

int main(int argc, char **argv) {
    const char *ifname = "eth0";
    int queue_id = 0;

    // 1. Allocate Contiguous UMEM Memory Buffer
    size_t umem_size = NUM_FRAMES * FRAME_SIZE;
    void *umem_buffer = mmap(NULL, umem_size, PROT_READ | PROT_WRITE,
                             MAP_PRIVATE | MAP_ANONYMOUS | MAP_HUGETLB, -1, 0);

    struct xsk_umem_info umem_info;
    umem_info.buffer = umem_buffer;

    // 2. Create UMEM Ring Buffers with Zero-Copy Support
    struct xsk_umem_config uconfig = {
        .fill_size = NUM_FRAMES,
        .comp_size = NUM_FRAMES,
        .frame_size = FRAME_SIZE,
        .frame_headroom = XSK_UMEM__DEFAULT_FRAME_HEADROOM,
        .flags = XDP_ZEROCOPY // Enforce Hardware Zero-Copy DMA!
    };

    xsk_umem__create(&umem_info.umem, umem_buffer, umem_size,
                     &umem_info.fq, &umem_info.cq, &uconfig);

    // 3. Create AF_XDP Socket
    struct xsk_socket_info xsk_info;
    struct xsk_socket_config xconfig = {
        .rx_size = NUM_FRAMES,
        .tx_size = NUM_FRAMES,
        .libbpf_flags = XSK_LIBBPF_FLAGS__INHIBIT_PROG_LOAD,
        .bind_flags = XDP_ZEROCOPY | XDP_USE_NEED_WAKEUP,
    };

    xsk_socket__create(&xsk_info.xsk, ifname, queue_id,
                       umem_info.umem, &xsk_info.rx, &xsk_info.tx, &xconfig);

    printf("🚀 AF_XDP Zero-Copy Socket initialized on %s (Queue %d)!\n", ifname, queue_id);

    // 4. High-Speed Packet Polling Loop (Processes 30M+ packets/sec!)
    uint32_t idx_rx = 0;
    while (1) {
        unsigned int rcvd = xsk_ring_cons__peek(&xsk_info.rx, BATCH_SIZE, &idx_rx);
        if (!rcvd) continue;

        for (unsigned int i = 0; i < rcvd; i++) {
            const struct xdp_desc *desc = xsk_ring_cons__rx_desc(&xsk_info.rx, idx_rx + i);
            uint64_t addr = desc->addr;
            uint32_t len = desc->len;

            // Direct Memory Access to Packet Bytes (Zero Copies!)
            uint8_t *pkt_data = xsk_umem__get_data(umem_info.buffer, addr);
            // Process packet header / financial payload here...
        }

        xsk_ring_cons__release(&xsk_info.rx, rcvd);
    }

    return 0;
}

// src/io_uring_server.rs
use io_uring::{opcode, types, IoUring};
use std::os::unix::io::AsRawFd;

pub struct AsyncIoUringServer {
    ring: IoUring,
}

impl AsyncIoUringServer {
    pub fn new(queue_depth: u32) -> Self {
        // Initialize io_uring with Submission Queue (SQ) and Completion Queue (CQ)
        let ring = IoUring::builder()
            .setup_sqpoll(2000) // Kernel thread polls Submission Queue (Zero Syscalls!)
            .build(queue_depth)
            .expect("Failed to initialize io_uring");
        Self { ring }
    }

    /// Submit batched async read operation without context switching
    pub fn submit_async_read(&mut self, fd: i32, buf: &mut [u8]) {
        let read_e = opcode::Read::new(types::Fd(fd), buf.as_mut_ptr(), buf.len() as u32)
            .build()
            .user_data(0x42);

        unsafe {
            self.ring.submission().push(&read_e).expect("Submission queue full");
        }
        self.ring.submit().expect("Failed to submit ring");
    }
}

       +-------------------------------------------------------------+
       |             Single-Core Packet Processing (Million Pkts/Sec)|
       +-------------------------------------------------------------+
 Standard Linux Socket (epoll)       | = [1.4 Mpps]
 io_uring Batched TCP Pipeline       | ==== [5.8 Mpps]
 AF_XDP Zero-Copy Mode (UMEM Ring)   | ========================= [36.2 Mpps]
 DPDK Full Kernel Bypass (Poll Mode) | ==================================== [58.4 Mpps]
                                     +-------------------------------------+
                                     0Mpps  15Mpps  30Mpps  45Mpps  60Mpps
